Name: City Owned Stormwater Structures

Display Field: FEATURE_ID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This feature class represents stormwater structure inventory in Boca RatonData is merged from several internal files, county, and state datasets to represent a complete network in the city. Data will be modified and updated by the Stormwater Operations team and inspections and maintenance will be completed in the following related tables:BOCADATA.CNEIRA.MS4_NPDES_CONTROL_STRUCTURE_INSPECTIONBOCADATA.CNEIRA.MS4_NPDES_INLETS_CB_INPSECTIONBOCADATA.CNEIRA.MS4_NPDES_PUMP_STATION_INSPECTIONBOCADATA.CNEIRA.MS4_NPDES_MAINTENANCE_LOG_STRUCTURES

Copyright Text: City of Boca Raton Municipal Services Engineering Cassandra Neira GIS Analyst

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 738743.5225159973
YMin: 722240.5667147413
XMax: 2467522.956682496
YMax: 1714107.4763496593
Spatial Reference: 102658  (2236)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSMSCircle
Color: [130, 130, 130, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Default Label:
UniqueValueInfos:
• Value: Catch Basin
  Label: Catch Basin
  Description: N/A
  Symbol:

• Value: Control Structure
  Label: Control Structure
  Description: N/A
  Symbol:
  Style: esriSMSSquare
  Color: [230, 0, 0, 255]
  Size: 10.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 1
• Value: Headwall
  Label: Headwall
  Description: N/A
  Symbol:

• Value: Inlet
  Label: Inlet
  Description: N/A
  Symbol:

• Value: Manhole
  Label: Manhole
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [0, 0, 0, 255]
  Size: 10.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: Pump Station
  Label: Pump Station
  Description: N/A
  Symbol:

• Value: Undetermined
  Label: Undetermined
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [190, 232, 255, 255]
  Size: 6.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerPointLabelPlacementAboveRight
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [255, 255, 255, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 7
Font Family: Arial Rounded MT Bold
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 5000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• FEATURE_ID ( type: esriFieldTypeString, alias: Feature ID, length: 50 )
• HANDLE ( type: esriFieldTypeString, alias: HANDLE, length: 20 )
• LAYER ( type: esriFieldTypeString, alias: LAYER, length: 50 )
• ELEVATION ( type: esriFieldTypeString, alias: RIM Elevation (ft), length: 20 )
• BOTTOM_ELEVATION ( type: esriFieldTypeDouble, alias: Bottom Elevation (ft) )
• TEXT ( type: esriFieldTypeString, alias: TEXT, length: 20 )
• NO ( type: esriFieldTypeInteger, alias: NO )
• TYPE ( type: esriFieldTypeString, alias: Type, length: 50 , Coded Values: [Catch Basin: Catch Basin] , [Closed Flume Inlet: Closed Flume Inlet] , [Control Structure: Control Structure] , ...14 more... )
• STATUS ( type: esriFieldTypeString, alias: Status, length: 50 , Coded Values: [Inspected: Inspected] , [Need to Verify: Need to Verify] , [Verified: Verified] , ...2 more... )
• ROW_TYP ( type: esriFieldTypeString, alias: ROW_TYP, length: 20 )
• VERIFIED ( type: esriFieldTypeString, alias: VERIFIED, length: 50 )
• OWNER ( type: esriFieldTypeString, alias: Asset Owner, length: 20 , Coded Values: [City: City] , [County: County] , [FDOT: FDOT] , ...2 more... )
• MANAGED_BY ( type: esriFieldTypeString, alias: Managed By, length: 255 , Coded Values: [City: City] , [County: County] , [FDOT: FDOT] , ...2 more... )
• COMMENTS ( type: esriFieldTypeString, alias: Comments, length: 50 )
• ADDED_BY_C ( type: esriFieldTypeString, alias: Year Last Inspected, length: 20 )
• LOCATION ( type: esriFieldTypeString, alias: Location, length: 225 )
• PROJECT_NO ( type: esriFieldTypeString, alias: Project Number, length: 255 )
• CUES_LINK ( type: esriFieldTypeString, alias: Cues Link, length: 255 )
• ASBUILT_LINK ( type: esriFieldTypeString, alias: Asbuilt Hyperlink, length: 255 )
• MORE_DOCUMENTS ( type: esriFieldTypeString, alias: Link to More Documents, length: 255 )
• FY_INSPECTED ( type: esriFieldTypeString, alias: Fiscal Year Last Inspected, length: 255 , Coded Values: [2021-2022: 2021-2022] , [2022-2023: 2022-2023] , [2023-2024: 2023-2024] , ...2 more... )
• INVERT_N ( type: esriFieldTypeDouble, alias: Invert North (ft) )
• INVERT_S ( type: esriFieldTypeDouble, alias: Invert South (ft) )
• INVERT_W ( type: esriFieldTypeDouble, alias: Invert West (ft) )
• INVERT_E ( type: esriFieldTypeDouble, alias: Invert East (ft) )
• INVERT_NE ( type: esriFieldTypeDouble, alias: Invert NE (ft) )
• INVERT_NW ( type: esriFieldTypeDouble, alias: Invert NW (ft) )
• INVERT_SE ( type: esriFieldTypeDouble, alias: Invert SE (ft) )
• INVERT_SW ( type: esriFieldTypeDouble, alias: Invert SW (ft) )
• NORTHING ( type: esriFieldTypeDouble, alias: NORTHING )
• EASTING ( type: esriFieldTypeDouble, alias: EASTING )
• DATUM ( type: esriFieldTypeString, alias: Datum, length: 255 )
• ESRIGNSS_POSITIONSOURCETYPE ( type: esriFieldTypeSmallInteger, alias: Position source type , Coded Values: [0: Unknown] , [1: User defined] , [2: Integrated (System) Location Provider] , ...2 more... )
• ESRIGNSS_RECEIVER ( type: esriFieldTypeString, alias: Receiver Name, length: 50 )
• ESRIGNSS_LATITUDE ( type: esriFieldTypeDouble, alias: Latitude )
• ESRIGNSS_LONGITUDE ( type: esriFieldTypeDouble, alias: Longitude )
• ESRIGNSS_ALTITUDE ( type: esriFieldTypeDouble, alias: Altitude )
• ESRIGNSS_H_RMS ( type: esriFieldTypeDouble, alias: Horizontal Accuracy (m) )
• ESRIGNSS_V_RMS ( type: esriFieldTypeDouble, alias: Vertical Accuracy (m) )
• ESRIGNSS_FIXDATETIME ( type: esriFieldTypeDate, alias: Fix Time, length: 8 )
• ESRIGNSS_FIXTYPE ( type: esriFieldTypeSmallInteger, alias: Fix Type , Coded Values: [0: Fix not valid] , [1: GPS] , [2: Differential GPS] , ...2 more... )
• ESRIGNSS_CORRECTIONAGE ( type: esriFieldTypeDouble, alias: Correction Age )
• ESRIGNSS_STATIONID ( type: esriFieldTypeSmallInteger, alias: Station ID , Range: [0, 1023] )
• ESRIGNSS_NUMSATS ( type: esriFieldTypeSmallInteger, alias: Number of Satellites , Range: [0, 99] )
• ESRIGNSS_PDOP ( type: esriFieldTypeDouble, alias: PDOP )
• ESRIGNSS_HDOP ( type: esriFieldTypeDouble, alias: HDOP )
• ESRIGNSS_VDOP ( type: esriFieldTypeDouble, alias: VDOP )
• ESRIGNSS_DIRECTION ( type: esriFieldTypeDouble, alias: Direction of travel (°) )
• ESRIGNSS_SPEED ( type: esriFieldTypeDouble, alias: Speed (km/h) )
• ESRISNSR_AZIMUTH ( type: esriFieldTypeDouble, alias: Compass reading (°) )
• ESRIGNSS_AVG_H_RMS ( type: esriFieldTypeDouble, alias: Average Horizontal Accuracy (m) )
• ESRIGNSS_AVG_V_RMS ( type: esriFieldTypeDouble, alias: Average Vertical Accuracy (m) )
• ESRIGNSS_AVG_POSITIONS ( type: esriFieldTypeSmallInteger, alias: Averaged Positions )
• ESRIGNSS_H_STDDEV ( type: esriFieldTypeDouble, alias: Standard Deviation (m) )
• DATA_SOURCE ( type: esriFieldTypeString, alias: Data Source, length: 255 , Coded Values: [MS Field Survey: MS Field Survey] , [MS NPDES Inspection: MS NPDES Inspection] , [Asbuilt Plan: Asbuilt Plan] , ...2 more... )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Relationships:

• MS4_NPDES_PUMP_STATION_INSPECTION (0) -- Related To: Pump Station Inspection Form (24)
• MS4_NPDES_CONTROL_STRUCTURE_INSPECTION (1) -- Related To: MS4 NPDES Control Structure Inspection Form (10)
• MS4_NPDES_INLETS_CB_INPSECTION (2) -- Related To: Inlets/Catch Basin/Manhole Inspection Form (18)
• MS4_NPDES_MAINTENANCE_LOG_STRUCTURES (3) -- Related To: Structures Maintenance Logs (30)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
