Name: City Owned Stormwater Pipes

Display Field: FEATURE_ID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This feature class represents stormwater pipes inventory in Boca Raton</SPAN></P><P><SPAN>Data is merged from several internal files, county, and state datasets to represent a complete network in the city. Pipes are inspected by gravity mains or exfiltration trench types. Data will be modified and updated by the Stormwater Operations team and inspections and maintenance logs will be completed in the following related tables:</SPAN></P><P><SPAN>MS4_NPDES_PIPES_CULVERTS_INSPECTION</SPAN></P><P><SPAN>MS4_NPDES_EXFILTRATION_TRENCH_INSPECTION</SPAN></P><P><SPAN>MS4_NPDES_MAINTENANCE_LOG_PIPES</SPAN></P></DIV></DIV></DIV>

Copyright Text: City of Boca Raton Municipal Services Engineering Cassandra Neira GIS Analyst

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8924429.329032501
YMin: 3038370.966580682
XMax: -8909991.413164224
YMax: 3052645.8424418494
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [85, 255, 0, 255]
Width: 3
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [255, 255, 255, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Arial Rounded MT Bold
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 5000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Handle ( type: esriFieldTypeString, alias: Handle, length: 16 )
• FEATURE_ID ( type: esriFieldTypeString, alias: Feature ID, length: 50 )
• Layer ( type: esriFieldTypeString, alias: Layer, length: 50 )
• LABEL ( type: esriFieldTypeString, alias: LABEL, length: 50 )
• LOCATION ( type: esriFieldTypeString, alias: Location, length: 10 )
• RIM ( type: esriFieldTypeDouble, alias: RIM )
• INV_N ( type: esriFieldTypeDouble, alias: INV_N )
• INV_S ( type: esriFieldTypeDouble, alias: INV_S )
• INV_E ( type: esriFieldTypeDouble, alias: INV_E )
• INV_W ( type: esriFieldTypeDouble, alias: INV_W )
• SOURCE_INF ( type: esriFieldTypeString, alias: SOURCE_INF, length: 50 , Coded Values: [MS Field Survey: MS Field Survey] , [MS NPDES Inspection: MS NPDES Inspection] , [Asbuilt Plan: Asbuilt Plan] , ...2 more... )
• DIA ( type: esriFieldTypeInteger, alias: Diameter )
• STATUS ( type: esriFieldTypeString, alias: Status, length: 50 , Coded Values: [Inspected: Inspected] , [Need to Verify: Need to Verify] , [Verified: Verified] , ...2 more... )
• DESC_ ( type: esriFieldTypeString, alias: Description, length: 50 )
• SURFACE_CO ( type: esriFieldTypeString, alias: Year Last Inspected, length: 50 )
• PIPE_SHAPE ( type: esriFieldTypeString, alias: Pipe Shape, length: 50 , Coded Values: [Elliptical: Elliptical] , [Exfiltration: Exfiltration] , [GOCFS: GOCFS] , ...2 more... )
• PIPE_MATER ( type: esriFieldTypeString, alias: Pipe Material, length: 50 , Coded Values: [CAP: CAP] , [Corrugated Aluminum: Corrugated Aluminum] , [CMP: CMP] , ...9 more... )
• ASSET_LENG ( type: esriFieldTypeDouble, alias: Asset Length )
• PIPE_HEIGH ( type: esriFieldTypeDouble, alias: Pipe Height )
• JOINT_DIST ( type: esriFieldTypeDouble, alias: JOINT_DIST )
• PIPE_WIDTH ( type: esriFieldTypeDouble, alias: Pipe Width )
• INCLINATIO ( type: esriFieldTypeDouble, alias: INCLINATIO )
• LINING_TYP ( type: esriFieldTypeString, alias: LINING_TYP, length: 50 )
• LINING_DAT ( type: esriFieldTypeDate, alias: LINING_DAT, length: 8 )
• COMMENTS ( type: esriFieldTypeString, alias: Comments, length: 200 )
• TYPE ( type: esriFieldTypeString, alias: Type, length: 50 , Coded Values: [CONVEYANCE: CONVEYANCE] , [EXFILTRATION: EXFILTRATION] , [UNKNOWN: UNKNOWN] , ...1 more... )
• CITY ( type: esriFieldTypeString, alias: City, length: 50 )
• ADDRESS ( type: esriFieldTypeString, alias: Address, length: 50 )
• UPSTREAM_N ( type: esriFieldTypeString, alias: Upstream North, length: 20 )
• DOWNSTREAM ( type: esriFieldTypeString, alias: Downstream, length: 20 )
• ASSET_OWNE ( type: esriFieldTypeString, alias: Asset Owner, length: 50 , Coded Values: [City: City] , [County: County] , [FDOT: FDOT] , ...2 more... )
• FY_INSPECTED ( type: esriFieldTypeString, alias: Fiscal Year Last Inspected, length: 255 , Coded Values: [2021-2022: 2021-2022] , [2022-2023: 2022-2023] , [2023-2024: 2023-2024] , ...2 more... )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• PROJECT_NO ( type: esriFieldTypeString, alias: Project Number, length: 255 )
• CUES_LINK ( type: esriFieldTypeString, alias: Cues Link, length: 255 )
• ASBUILT_LINK ( type: esriFieldTypeString, alias: Asbuilt Hyperlink, length: 255 )
• MORE_DOCUMENTS ( type: esriFieldTypeString, alias: Link to More Documents, length: 255 )
• DATUM ( type: esriFieldTypeString, alias: Datum, length: 255 )
• MANAGED_BY ( type: esriFieldTypeString, alias: Managed By, length: 255 , Coded Values: [City: City] , [County: County] , [FDOT: FDOT] , ...2 more... )

Relationships:

• MS4_NPDES_EXFILTRATION_TRENCH_INSPECTION (10) -- Related To: Exfiltration Trench Inspection Form (14)
• MS4_NPDES_PIPES_CULVERTS_INSPECTION (11) -- Related To: Pipes/Culverts Inspection Form (22)
• MS4_NPDES_MAINTENANCE_LOG_PIPES (12) -- Related To: Pipes Maintenance Logs (28)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
